Deadbolts
D101 AB Deadbolts
A deadbolt in antique brass (US5), prepared for a solid brass cylinder.
- Key Features
- Construction
- Internal parts made of zinc-plated steel for durability
- Exterior trim available in stainless steel, brass, or steel
- Free-spinning cylinder trim protects against wrench attacks
- Deadbolt Mechanism
- 1-inch (25mm) throw bolt made of zinc alloy
- Hardened steel roller insert improves anti-sawing performance
- Cylinder & Keys
- 5-pin tumbler system, easy to rekey
- Solid brass plug with two nickel-plated brass keys included
- Optional configurations: Single or Double Cylinder
- Universal handing, suitable for both left-hand and right-hand doors
- No need to specify when ordering, field-reversible
- Compatible with standard wooden or metal doors
- Adjustable to fit a wide range of door thicknesses and backsets
For a quotation, send the model and finish, the quantity, the destination country, and a drawing or photograph of anything you want changed.
Or email us about this model: tec@cantonlock.com
Opens our storefront already searched for this model — trade assurance, tiered pricing and order tracking are handled there.
Technical specifications
- Cylinder
- Solid Brass Cylinder
- Deadbolt throw
- 25mm, zinc die-cast with hardened steel roller insert (1")
- Chassis
- Zinc plated steel internal components
- Trim
- Stainless steel, brass or steel
- Handing
- Fully reversible, left or right hand
- Feature
- Free-turning cylinder trim prevents wrenching; cylinder removable for rekeying
- Keying
- Can be keyed to pair with an entrance bored lock
- Finish
- Antique brass (US5)
- Exposed Trim Material
- Stainless Steel / Brass / Steel
- Key options
- 2 Nickel-Plated Brass Keys
- Door thickness
- Adjustable 1-3/8” to 1-3/4” (35mm–45mm) (1/8" / 1-3/8" / 1-3/4")
- Backset
- Adjustable 2-3/8” or 2-3/4” (60mm or 70mm) (1/8" / 2-3/8" / 2-3/4")
Bolt detail
Backset 60mm to the cylinder center. Deadbolt throw 25mm. Case outline is not published and is therefore not drawn.
Drawn 1:1 from the published specification · Case outline is not published; only the dimensions stated below are drawn.
Common questions
- Which finishes is the D101 AB available in?
- The D101 AB is available in Antique brass (US5).
- What backset does the D101 AB use?
- The D101 AB has a backset of Adjustable 2-3/8” or 2-3/4” (60mm or 70mm).
- What door thickness does the D101 AB suit?
- The D101 AB suits a door thickness of Adjustable 1-3/8” to 1-3/4” (35mm–45mm).
- Is the D101 AB handed?
- Handing for the D101 AB: Fully reversible, left or right hand.
- What cylinder does the D101 AB take?
- The D101 AB takes a Solid Brass Cylinder cylinder.
