D101 DSPB Deadbolts
Model
D101 DSPB
A stainless steel deadbolt, single cylinder function, for entrance doors.
- Economical and durable auxiliary deadbolt
- 25mm (1”) zinc die-cast bolt with hardened steel roller insert for anti-saw protection
- Zinc-plated steel internal components
- Free-turning cylinder trim to prevent wrenching
- 5-pin solid brass cylinder, easy to rekey
- Supplied with 2 nickel-plated brass keys
- Can be keyed alike with entrance locks for enhanced exterior security
For a quotation, send the model and finish, the quantity, the destination country, and a drawing or photograph of anything you want changed.
Or email us about this model: tec@cantonlock.com
Opens our storefront already searched for this model — trade assurance, tiered pricing and order tracking are handled there.
Technical specifications
- Material
- Stainless steel body
- Function
- Single cylinder
- Application
- Entrance doors
- Deadbolt throw
- 25mm, zinc die-cast with hardened steel roller insert (1")
- Cylinder
- 5-pin tumbler, solid brass plug, two nickel-plated brass keys
- Chassis
- Zinc plated steel internal components
- Trim
- Stainless steel, brass or steel
- Handing
- Fully reversible, left or right hand
- Feature
- Free-turning cylinder trim prevents wrenching; cylinder removable for rekeying
- Keying
- Can be keyed to pair with an entrance bored lock
- Trim Material
- Stainless steel, brass, or steel
- Door thickness
- Adjustable 35–45mm (1-3/8” to 1-3/4”) (1-3/8" to 1-3/4")
- Backset
- Adjustable 60mm or 70mm (2-3/8” or 2-3/4”) (2-3/8" / 2-3/4" / 1/8")
Bolt detail
Backset 60mm to the cylinder center. Deadbolt throw 25mm. Case outline is not published and is therefore not drawn.
Drawn 1:1 from the published specification · Case outline is not published; only the dimensions stated below are drawn.
Common questions
- What is the D101 DSPB made from?
- The D101 DSPB is made from Stainless steel body.
- What backset does the D101 DSPB use?
- The D101 DSPB has a backset of Adjustable 60mm or 70mm (2-3/8” or 2-3/4”).
- What door thickness does the D101 DSPB suit?
- The D101 DSPB suits a door thickness of Adjustable 35–45mm (1-3/8” to 1-3/4”).
- What function does the D101 DSPB provide?
- The D101 DSPB provides Single cylinder.
- Where is the D101 DSPB used?
- The D101 DSPB is used on Entrance doors.
- Is the D101 DSPB handed?
- Handing for the D101 DSPB: Fully reversible, left or right hand.
