Grip Handle Set
70710 SN Grip Handle Set
A zinc alloy grip handle set in SN=Satin nickel with 60mm / 70mm adjustable, latch and deadbolt both backset.
- Key Features:
- Enhanced Security
- – 1” (25mm) solid deadbolt with hardened steel insert
- – 1/2” (13mm) latch bolt extension
- – Free-spinning cylinder ring resists wrenching
- – No exposed external fasteners
- Easy Installation
- – Fits standard 2” (51mm) cross bore
- – Adjustable backset: 2-3/8” or 2-3/4” (60mm or 70mm)
- – Reversible for left/right-handed doors
- – Fits door thickness: 1-3/8” to 1-3/4” (35–45mm)
- Stylish grip handle set designed to enhance the appearance and security of entrance doors. Made of durable zinc alloy with satin nickel finish, compatible with standard door preps and easy to install.
For a quotation, send the model and finish, the quantity, the destination country, and a drawing or photograph of anything you want changed.
Or email us about this model: tec@cantonlock.com
Opens our storefront already searched for this model — trade assurance, tiered pricing and order tracking are handled there.
Technical specifications
- Material
- Zinc alloy
- Finish
- SN=Satin Nickel
- Backset
- 60mm / 70mm adjustable, latch and deadbolt both (2-3/8" / 2-3/4")
- Door thickness
- 35mm to 45mm adjustable (1-3/8" / 1-3/4")
- Deadbolt throw
- 25mm, with hardened steel insert to resist sawing (1")
- Latch extension
- 13mm (1/2")
- Cross bore
- 51mm, replaces most existing locksets (2")
- Chassis
- Solid steel internal construction, corrosion protected
- Trim
- Forged solid brass or zinc die-casting electro-plated
- Handing
- Non-handed, left or right hand
- Feature
- No exposed exterior fixings; free-turning cylinder ring resists wrenching
Bolt detail
Backset 60mm to the cylinder center. Latch throw 13mm. Deadbolt throw 25mm. Case outline is not published and is therefore not drawn.
Drawn 1:1 from the published specification · Case outline is not published; only the dimensions stated below are drawn.
Common questions
- What is the 70710 SN made from?
- The 70710 SN is made from Zinc alloy.
- Which finishes is the 70710 SN available in?
- The 70710 SN is available in SN=Satin Nickel.
- What backset does the 70710 SN use?
- The 70710 SN has a backset of 60mm / 70mm adjustable, latch and deadbolt both.
- What door thickness does the 70710 SN suit?
- The 70710 SN suits a door thickness of 35mm to 45mm adjustable.
- Is the 70710 SN handed?
- Handing for the 70710 SN: Non-handed, left or right hand.
