Night Latch And Rim Lock
5833 Night Latch And Rim Lock
Model
5833
Iron and Brass night latch and rim lock, 50mm backset.
For a quotation, send the model and finish, the quantity, the destination country, and a drawing or photograph of anything you want changed.
Or email us about this model: tec@cantonlock.com
Opens our storefront already searched for this model — trade assurance, tiered pricing and order tracking are handled there.
Technical specifications
- Application
- Iron Door
- Material
- Iron and Brass
- Cylinder
- Double
- Backset
- 50mm (1-15/16")
- Door thickness
- 35mm to 55mm standard; 30mm to 60mm on request (1-3/8" / 2-3/16" / 1-3/16" / 2-3/8")
- Latch extension
- 13mm, with inside deadlocking button (1/2")
- Deadbolt throw
- 25mm on rim deadbolt versions (1")
- Strike
- Angle strike standard for inward-opening doors; flat strike available
- Handing
- Fully reversible, left or right hand
- Function
- Single cylinder, double cylinder or self-locking
- Feature
- Anti-picking slide gate on single-cylinder deadlock
- Key
- 3 Brass Keys
- OEM & Sample
- Accepted
- Market
- South America
Bolt detail
Backset 50mm to the cylinder center. Latch throw 13mm. Deadbolt throw 25mm. Case outline is not published and is therefore not drawn.
Drawn 1:1 from the published specification · Case outline is not published; only the dimensions stated below are drawn.
Common questions
- What is the 5833 made from?
- The 5833 is made from Iron and Brass.
- What backset does the 5833 use?
- The 5833 has a backset of 50mm.
- What door thickness does the 5833 suit?
- The 5833 suits a door thickness of 35mm to 55mm standard; 30mm to 60mm on request.
- What function does the 5833 provide?
- The 5833 provides Single cylinder, double cylinder or self-locking.
- Where is the 5833 used?
- The 5833 is used on Iron Door.
- Is the 5833 handed?
- Handing for the 5833: Fully reversible, left or right hand.
