598 SSET Tubular Lock

Material

Stainless Steel

Cylinder

Brass cylinder

Finish

Satin stainless steel (US32D)

Backset

60mm / 70mm adjustable (2-3/8" / 2-3/4")

Door thickness

35mm to 45mm adjustable (1-3/8" / 1-3/4")

Cycle life

200,000 cycles

Chassis

Solid steel chassis and latch case, zinc plated

Trim

Wrought stainless steel or brass

Strike

57mm curved lip standard; 70mm available on request (2-1/4" / 2-3/4")

Handing

Fully reversible, left or right hand

Application

Residential use

Function

Entrance, keyed outside

Download the spec sheet (PDF)

Dimensioned drawing

Door preparation: backset 60mm, door thickness 35mm.

Drawn 1:1 from the published specification

What is the 598 SSET made from?

The 598 SSET is made from Stainless Steel.

Which finishes is the 598 SSET available in?

The 598 SSET is available in Satin stainless steel (US32D).

What backset does the 598 SSET use?

The 598 SSET has a backset of 60mm / 70mm adjustable.

What door thickness does the 598 SSET suit?

The 598 SSET suits a door thickness of 35mm to 45mm adjustable.

What function does the 598 SSET provide?

The 598 SSET provides Entrance, keyed outside.

How many cycles is the 598 SSET tested to?

The 598 SSET is tested to 200,000 cycles.

1. 1Model and finish598 SSET, and the finish or color
2. 2QuantityPer order, and per year if it repeats
3. 3Destination countryFor freight and export documents
4. 4ChangesA drawing or photograph of anything you want changed
