A 304 stainless steel glass door handle in satin+polished.
Or email us about this model: tec@cantonlock.com
Find 104 on our Alibaba storefront
Opens our storefront already searched for this model — trade assurance, tiered pricing and order tracking are handled there.
Technical specifications
- Material
- 304 stainless steel
- Finish
- Satin+Polished
- Tube Thickness
- 0.8 mm or 1.0 mm
- Door thickness
- 10–12 mm
- Length
- 600mm
- Centre distance
- 149mm at the head, 133mm at the foot — tapered
- Tube diameter
- 32mm, tapering to 19mm
- Standoff
- 26mm
- Fixing centre
- 34mm
- Glass gap
- 8mm
Dimensioned drawing
Length 600mm, centre distance 149mm, tube Ø32mm.
Drawn 1:1 from the published specification
Common questions
- What is the 104 made from?
- The 104 is made from 304 stainless steel.
- Which finishes is the 104 available in?
- The 104 is available in Satin+Polished.
- What door thickness does the 104 suit?
- The 104 suits a door thickness of 10–12 mm.
- What is the centre distance on the 104?
- The centre distance on the 104 is 149mm at the head, 133mm at the foot — tapered.
- What size is the 104?
- The 104 measures 600mm.
