Floor Spring
DZ-2087 Floor Spring
Model
DZ-2087
45# steel double-action floor spring for timber and metal doors. Max door weight 150kg / 200kg.
For a quotation, send the model and finish, the quantity, the destination country, and a drawing or photograph of anything you want changed.
Or email us about this model: tec@cantonlock.com
Opens our storefront already searched for this model — trade assurance, tiered pricing and order tracking are handled there.
Technical specifications
- Variants
- DZ-2087.150 / DZ-2087.200
- Double action
- Yes
- Max door width (spindle to edge)
- ≤850mm / ≤1000mm (33-7/16" / 39-3/8")
- Min door thickness
- ≥45mm (1-3/4")
- Max door weight
- 150kg / 200kg
- Max opening angle
- 360°
- 90° hold-open
- Yes
- Two-stage closing valve
- Yes
- Closing force
- EN4 / EN5
- Material
- 45# steel
- Available finishes
- Satin stainless · Matt black
- Suitable door types
- Wooden Door · Metal Door
Additional product views are not yet available. Request drawings or samples from our export team.
