أدلة أجهزة لقرارات ما قبل أمر الشراء. الأبعاد والمواد والمعايير والأسئلة التي تستحق الطرح.
ابحث عن دليل
45 guides
مواضيع أخرى
From a drawing or a sample to the first shipment: what can be changed on a door hardware part, what needs a new mould, how long tooling took on our own 311, minimum orders and samples, and who is responsible for the dimensions.
اقرأ الدليلمواضيع أخرى
يطلب المشترون مفصلات من النحاس الأحمر؛ وما يحمل الباب فعلًا هو النحاس الأصفر، أي النحاس الأحمر مسبوكًا مع الزنك. ما الذي قد تعنيه العبارة، ولماذا النحاس الأحمر العتيق مجرد تشطيب، وأي مفصلاتنا من النحاس الأصفر، وما الذي يُكتب في الطلب.
اقرأ الدليلمواضيع أخرى
59 قفلًا بمقبض كروي أو مقبض ذراع للأبواب المثقوبة، في أربع عائلات: أنبوبية، وأسطوانية للخدمة الخفيفة، وأسطوانية للخدمة الشاقة، وتجارية. جنبًا إلى جنب من بنود مواصفاتها، مع البند الوحيد الذي لا يفرّق بينها، والبنود التي تفرّق.
اقرأ الدليلمواضيع أخرى
46 records sit in our panic exit device family, and only 27 of them are exit devices. Here they are in three tables (single doors, pairs, special purposes) built from their specification rows, with the missing rows and the conflicting ones named.
اقرأ الدليلالأبعاد والملاءمة
32 of our mortise lock cases publish both a backset and a center distance. Here they are in two tables, narrow-stile and standard, with the naming traps and the gaps stated plainly.
اقرأ الدليلالأبعاد والملاءمة
رقمان يحسمان إن كان القفل البديل سيركب في باب مشغول مسبقًا: مسافة الظهر ونطاق سماكة الباب. هذا ما يضمه كتالوجنا المنشور فعلًا (معدودًا من السجلات لا منقولًا عن كتيّب)، مع المقابلات بالبوصة، وطريقة القياس، والبُعد الوحيد الذي ليس مسافة ظهر ويُخلط بها.
اقرأ الدليلالمواد والتشطيبات
«النحاس المصمت» اسم لعائلة من السبائك تختلف في سلوكها، والفرق الأهم هو هل تقاوم السبيكة نزع الزنك. تعرض هذه الصفحة سبائك النحاس المستخدمة في تجهيزات الأبواب، وتشرح سبب وجود الرصاص في معظمها وتكلفة البدائل منخفضة الرصاص، وتصف نزع الزنك والمواضع التي يُشترط فيها نحاس DZR فعلًا، وتفصل بين النحاس الأصفر والبرونز، وتعدّ ما ينشره كتالوجنا.
اقرأ الدليلالمعايير والاختبار
الشهادة إما تصمد أمام التحقق وإما لا، والتحقق منها يستغرق نحو خمس دقائق إذا عرفت ما تنظر إليه. تعرض هذه الصفحة الأجزاء السبعة التي تحملها كل شهادة اختبار حقيقية، وتشرح الفرق بين الاعتماد والتصديق، وتتناول إعلانات الأداء وعلامة CE لتجهيزات الأبواب، وتسرد العلامات التحذيرية الست التي تعني التوقف، وتذكر صراحة ما نحمله وما لا نحمله.
اقرأ الدليلالمواد والتشطيبات
الكروم طبقة علوية رقيقة فوق النيكل، ولهذا يحسم النيكل مظهره ومدة بقائه. تشرح هذه الصفحة طبقات الطلاء، وتفصل بين الكروم المصقول والكروم الساتان والنيكل الساتان بالخاصية التي تميّزها فعلًا، وتذكر الرموز، وتُظهر من 336 بندًا للتشطيب في كتالوجنا لماذا لا يمكن إعادة طلب تشطيب مكتوب باسمه لا برمزه.
اقرأ الدليلالأبعاد والملاءمة
اختيار وظيفة القفل ليس مشكلة كتالوج، بل مشكلة سؤالين: من يُسمح له بالعبور، وماذا يحدث للشخص الموجود في الداخل. تحوّل هذه الصفحة ذلك إلى جدول قرار يغطي أنواع الغرف التي يضمها المبنى التجاري فعلًا، وتسمّي أخطاء الوظيفة الثلاثة التي تخلق مشكلات سلامة أرواح لا مجرد إزعاج، وتذكر عدد الطرازات التي يضمها كتالوجنا من كل وظيفة.
اقرأ الدليلالطلب والتسليم
تجهيزات الأبواب شحنة يحدّها الوزن لا الحجم. محسوبًا من ورقة الشحن الخاصة بنا: الكثافة الوسيطة للكرتونة 614 kg لكل متر مكعب، وهي فوق النقطة التي تنفد عندها حمولة الحاوية 40 قدمًا قبل أن تنفد مساحتها. الحاوية المرتفعة تشتري حجمًا أكبر بنسبة 15 في المئة، ولا تشتري لهذه الشحنة أي تجهيزات إضافية.
اقرأ الدليلالمعايير والاختبار
يصنّف EN 1670 مقاومة تجهيزات الأبواب للتآكل من 0 إلى 5، وكل درجة عدد من الساعات في حجرة رذاذ ملحي متعادل. تذكر هذه الصفحة الساعات لكل درجة، وتشرح ما يفعله ASTM B117 وANSI/BHMA A156.18 على الضفة الأخرى من الأطلسي، وتسمّي البيئات الثلاث التي تفشل فيها الدرجة المختارة بحكم العادة، وتصدق في ذكر ما لا يستطيع اختبار الحجرة التنبؤ به.
اقرأ الدليلالمعايير والاختبار
ننشر 200,000 دورة على 132 طرازًا. في EN 1906 هذه أعلى فئة متانة. وفي ANSI/BHMA A156.2 هي درجة الدخول. القولان صحيحان، والمواصفة التي تقرأ أحدهما على أنه الآخر إما ستشتري أكثر من اللازم وإما أقل منه. تعرض هذه الصفحة ما اختبار الدورات فعلًا، وما يطلبه كل مقياس، وأين يقع رقمنا على كليهما.
اقرأ الدليلالأبعاد والملاءمة
"Is it interchangeable?" is answered by seven dimensions, and two of them are the ones almost nobody publishes. This page lists them in the order they cause failures, explains why matching the backset is not enough, sets out what to send a factory when you want a drop-in for a discontinued lock, and counts how many of our own 258 lock products publish each dimension, including the one at two per cent.
اقرأ الدليلالأبعاد والملاءمة
The same door closer performs differently depending on where it is mounted, and the mounting is usually chosen on site by whoever is holding the drill. This page compares the four standard arrangements on the three things that matter (mechanical efficiency, projection into the opening, and vulnerability) explains why a parallel arm can cost you a power size, and sets out which side of the door each one lives on.
اقرأ الدليلالأبعاد والملاءمة
A door closer is specified by a power size, and the power size is derived from the door (its leaf width and its mass) not from the opening or the building type. This page sets out the EN 1154 size ladder with the leaf widths each covers, how the ANSI/BHMA A156.4 approach differs, the three adjustments that are not the power size, and the accessibility constraint that overrides all of it.
اقرأ الدليلالطلب والتسليم
Almost every product in a door hardware catalog classifies under one of two HS headings: 8301 for locks and keys, 8302 for mountings and fittings. This page sets out the subheadings under each, names the four that are most often got wrong (door closers, keys shipped separately, parts, and furniture versus building fittings) and explains exactly where the internationally agreed code ends and your own country's begins.
اقرأ الدليلالأبعاد والملاءمة
A door arrives on site "prepped", and whether the lock fits is decided by holes cut weeks earlier in another factory. This page sets out the standard bored-lock and mortise-lock preparations with their dimensions, explains the ANSI/BHMA A115 series that governs them, and lists the five things a purchase order has to say before a door manufacturer can cut anything.
اقرأ الدليلالأبعاد والملاءمة
Sizing a euro cylinder is one subtraction and one rounding, and the rounding is where it goes wrong. This page gives the calculation, a door-thickness lookup table worked against the nine lengths we actually publish, explains why a thin door still gets a protruding cylinder, and shows what changes when the lock case is not centered in the leaf.
اقرأ الدليلالمعايير والاختبار
Two European standards cover escape hardware and they are chosen by who uses the building, not by how important the door is. This page explains what separates EN 1125 from EN 179, gives the occupancy test that decides between them, decodes the classification digits, lists the three mistakes that produce a non-compliant opening, and states what our own exit range does and does not hold.
اقرأ الدليلالمعايير والاختبار
Specifiers ask for a conversion table between EN and ANSI/BHMA door hardware standards. What exists is a scope map, not an equivalence: the two systems classify different properties, and a product certified to one carries no automatic claim under the other. This page sets out which standard covers which product family on each side, what each one measures, and the four places the mapping genuinely breaks.
اقرأ الدليلالأبعاد والملاءمة
A euro cylinder is described by two numbers, and getting them the wrong way round is the commonest ordering error in door hardware. This is the full size chart to EN 1303 and DIN 18252 geometry, the nine overall lengths we publish, the split combinations that add up to each one, and the measurement that decides which you need.
اقرأ الدليلالأبعاد والملاءمة
An exit device has two halves and only one of them is a decision. The bar inside always lets people out; the trim outside decides who gets in, whether the door can be held unlocked during business hours, and whether the opening still complies in a fire. This page compares every outside trim function, sets out the dogging rules including the one that is absolute on fire doors, and counts how many of our own fifteen trims publish their function.
اقرأ الدليلالمواد والتشطيبات
A finish code on a purchase order decides what arrives, and four pairs of codes in common use are reversals of each other. This is the reference: the 23 codes our catalog uses, how they line up with BHMA 600-series and US26x numbers, the pairs that get transposed, and a count of how inconsistently our own catalog spells them.
اقرأ الدليلالمعايير والاختبار
A fire door is not a product; it is a tested assembly, and every item fixed to it is part of what was tested. This page lists the components that must be rated, explains the difference between EN 1634-1 and UL 10C / NFPA 252 including the hose stream test that only one of them has, sets out what a certificate actually covers, and states plainly which of our own products do and do not carry a fire rating today.
اقرأ الدليلالأبعاد والملاءمة
Glass door hardware is the only category where getting the sequence wrong destroys the door rather than delaying it. This page gives the glass thickness ranges our fittings actually accept, explains the glass gap dimension and the corner radius on a cut-out, sets out why every hole must be made before toughening, and lists what has to be on the glass shop drawing before anybody orders anything.
اقرأ الدليلالأبعاد والملاءمة
On a refurbishment the drawings are a record of what was intended, not of what is on the doors. This page gives the fourteen fields worth recording per leaf, separates the ones you can capture from the corridor from the ones that need a screwdriver, sets out a sampling rule by door type, and shows how the survey becomes an order.
اقرأ الدليلالطلب والتسليم
A warranty is read as a number of years and decided by its exclusions. This page separates warranty from guarantee from statutory rights, lists the five exclusions that defeat most claims, explains why installation and cleaning are where liability actually lands, sets out what a claim needs to succeed, and says what a factory can honestly promise about a part it will never see again.
اقرأ الدليلالأبعاد والملاءمة
Two questions decide a hinge specification: what grade, and how many. EN 1935 answers the first with grades 1 to 14 tied to a tested door mass; ANSI/BHMA A156.1 answers it with a weight class and a frequency. Neither answers the second, which is governed by leaf height and mass. This page sets out both ladders, the count rule, and the three failure modes that come from getting the count right and the grade wrong.
اقرأ الدليلالأبعاد والملاءمة
A key that enters a lock and a key that turns it are two different achievements, and the difference is the keyway. This page explains what a blank and a profile are, separates open from restricted from patented keyways, is precise about what each one stops and what it does not, explains why a patent expiring changes the security of a building that was specified years earlier, and lists what a buyer has to decide before a master key system can be cut.
اقرأ الدليلالمعايير والاختبار
A straight lever handle looks cleaner than a returned one and is rejected on most commercial specifications, for a reason that has nothing to do with taste. This page explains what lever return is, the safety and accessibility requirements behind it, why a knob fails accessibility where a lever passes, and how to read the eight fields of an EN 1906 handle classification instead of quoting only the first one.
اقرأ الدليلالأبعاد والملاءمة
A master key system is designed once and lived with for twenty years, and almost every system that runs out of room ran out for the same two reasons: too many levels for the building, and cross-keying granted door by door as favors. This page sets out the hierarchy, explains why every master level and every cross-key consumes capacity from a finite pool, and gives the questions to answer before a single cylinder is cut.
اقرأ الدليلالمعايير والاختبار
"Send the material certificate" means four different documents, and the difference between them is who signed it and whether the test was on your metal. This page sets out the EN 10204 document types, explains heat numbers and where the chain of custody genuinely breaks in small hardware, separates material traceability from RoHS and REACH compliance, and says which of these a door hardware factory can honestly provide.
اقرأ الدليلالطلب والتسليم
A buyer asks for a minimum order quantity and gets a range, which reads as evasion and is not. This page explains the four things that actually set an MOQ (the finish batch, the tooling, the packaging and the model's own production run) why our published range runs from 300 to 5,000 pieces, what the 30-day lead time is actually counting, and the three decisions a buyer can make that move all of these in their favor.
اقرأ الدليلالمواد والتشطيبات
A RAL number names a color and nothing else, not gloss, not texture, not process, not durability. This page explains what RAL specifies and what it leaves open, why pretreatment decides whether a coating survives, where powder coating fails on hardware geometry, which tests are worth citing, and the four lines that make a finish orderable.
اقرأ الدليلالطلب والتسليم
Three kinds of company answer a hardware inquiry and all three will say yes. This page explains what a factory, a trading company and a broker each actually control, gives five questions whose answers separate them without anybody having to be confronted, lists what can be verified independently, and applies the whole test to us.
اقرأ الدليلالطلب والتسليم
A sample is the cheapest place to discover that a supplier understood something differently from how you meant it. This page sets out the three kinds of sample and which one to ask for, the golden sample procedure that makes a sample enforceable instead of decorative, exactly what to measure when one arrives, the three properties a sample genuinely cannot demonstrate, and how to write an inspection standard that a third-party inspector can apply without calling you.
اقرأ الدليلالطلب والتسليم
A door hardware specification is a three-part document with a fixed shape, and most of the money lost on a hardware package is lost by putting the right sentence in the wrong part. This page sets out what belongs in Part 1, Part 2 and Part 3, shows how a hardware set is written so a factory can quote it without a phone call, and names the four clauses that quietly decide the price.
اقرأ الدليلالأبعاد والملاءمة
The spindle is the cheapest part of a door handle set and the one that most often makes a shipment unusable. Three numbers decide whether a handle will turn a lock: the square size, the spindle length, and whether the spindle is solid or split. This page sets out all three, gives the length formula, and shows what our own catalog actually publishes.
اقرأ الدليلالمواد والتشطيبات
201, 304 and 316 look identical in the hand and behave very differently on a building. This page sets out what separates them chemically, where each belongs, what the cost difference actually is, and then does the uncomfortable part, counts how many of our own 313 stainless products name a grade at all, and explains why a specification that says "304/201" has answered nothing.
اقرأ الدليلالأبعاد والملاءمة
The strike is the cheapest component in a door opening and the one that decides whether the lock ever latches properly. This page sets out the two standard North American strike sizes, the European keep conventions, how to work out lip length instead of guessing it, the difference between square and radius corners, and why a security upgrade that stops at the lock has upgraded nothing.
اقرأ الدليلالطلب والتسليم
A hardware submittal is rejected for the same handful of reasons on almost every project, and none of them is the hardware. This page lists what a complete package contains, names the four omissions that send it back, explains the difference between a product datasheet and evidence, sets out who signs what, and states plainly which of these documents we publish, which we supply on request, and which we do not have at all.
اقرأ الدليلالطلب والتسليم
Asking a hardware factory for "the CAD" produces a different file in every country, and half the time the file you get cannot do the job you wanted it for. This page separates the three kinds of drawing that answer three different questions, compares the formats and what each one is really for, explains why a 3D solid often does not exist even at a competent factory, and states our own drawing coverage as a number rather than a promise.
اقرأ الدليلالأبعاد والملاءمة
"Universal" means three different things in a hardware catalog and only one of them means you can stop thinking about handing. This page separates non-handed from field-reversible from factory-handed, names the four products that are handed when people assume they are not, explains what reversing actually does inside a lock, and gives the line to put on an order so the question never arrives.
اقرأ الدليلالمواد والتشطيبات
Zinc alloy is the second most common material in our catalog and the one buyers are most suspicious of, usually for reasons that describe bad castings rather than the material. This page explains what zamak is, what die casting is genuinely good at, the four distinct ways a poor zinc part fails, where zinc should never be used at all, and what to ask a factory so the answer means something.
اقرأ الدليلرمز التشطيب أكثر من مجرد لون. تعرّف على الرموز المنشورة والفروق المهمة عند تحديد مواصفات الأجهزة.
اقرأ الدليل
كل رقم يجب أن يعود إلى مصدر منشور. وحيث لا تكون القيمة منشورة، نقول ذلك بدل تقديرها.
